ANWETECH DM106 is an addressable output module for fire alarm systems, powered by a non-polar two-wire signal loop. It provides dry contact relay output with selectable normally open or normally closed contact logic, making it ideal for external fire alarm linkage and control applications.
The ANWETECH DM106 Addressable Output Module is designed for use in compatible addressable fire alarm systems. Powered directly by the non-polar two-wire signal loop, the module provides a dry contact relay output after activation, allowing it to control or link with external fire alarm equipment and other auxiliary devices.
The module supports both normally open and normally closed output logic, giving engineers more flexibility in system design. It features low loop current consumption, full electronic addressing by encoder, and simple on-site commissioning. For installation, debugging and maintenance, DM106 is used together with the DZ-9073 base.
With compact dimensions, stable performance and easy loop integration, DM106 is suitable for commercial, industrial and public building fire alarm projects that require reliable addressable output control.
| Item | Specification |
|---|---|
| Model | DM106 |
| Product Type | Addressable output module / relay output module |
| Operating Voltage | Signal loop 24 V DC (20 V to 28 V) |
| Loop Wiring | Non-polar two-wire loop, L1 / L2 |
| Standby Current | < 0.5 mA |
| Action Current | < 5 mA |
| Output Type | Dry contact relay output, normally open and normally closed |
| Output Capacity | 5 A @ 250 VAC |
| Programming Method | Electronic addressing by encoder |
| Address Range | 1 to 324 |
| Address Quantity | Occupies one address on the loop |
| Indicator Status | Blinks once about every 12 seconds in inspection status; remains lit in activation status |
| Operating Temperature | -10 °C to +55 °C |
| Relative Humidity | ≤95% RH, non-condensing |
| Enclosure Material | ABS |
| Overall Dimensions | 86 mm × 86 mm × 45 mm (with base) |
| Mounting Hole Distance | 60.5 mm |
| Weight | Approx. 148 g (with base) |
| Base Type | DZ-9073 independent base |
| Terminal / Port | Description |
|---|---|
| L1 / L2 | Loop in and loop out connections, non-polarized |
| NC1 / COM1 | Normally closed dry contact output |
| NC2 / COM2 | Normally open dry contact output |
| Module State | NC1-COM1 | NC2-COM2 | Meaning |
|---|---|---|---|
| Standby / Normal | Closed | Open | Normal monitoring status |
| Activated | Open | Closed | Relay output operates for external linkage |
